C3Z-D100 Square Shaped One-Touch Setting of Photoelectric Switches Sensor
C3Z-D100 is a diffuse reflection square photoelectric switch.Its detection distance is 100cm.This detection distance is adjustable within the range.Each series is available in NPN and PNP models.
Photoelectric switch is a position sensor with switching output, which can be networked with a microcomputer; it can also directly drive electromagnetic relays, counters and contactors to achieve automatic control. It is widely used in machinery, textiles, light industry, metallurgy, papermaking, and printing , packaging, tobacco, security, railway, military and other industries.
If you have any questions, please do not hesitate to contact us at
Email: [email protected]
- Description
| Specification | Diffuse reflective | |
| DC | NPN | C3Z-D100N |
| PNP | C3Z-D100P | |
| Detection distance※1 | 100cm( Adjustable) | |
| Sensitivity adjustment | One-touch button setting | |
| Standard detection object | 10×10cm White non-glossy paper | |
| Detectable objects | Reflecting object | |
| Response time | 2ms | |
| Return Difference | Less than 15 % of detection distance | |
| Supply Voltage | DC10 ～ 30V | |
| Operating current | Load current≤ 100mA；Static current：DC(NPN) ≤ 25mA、DC(PNP) ≤ 35mA | |
| Residual voltage | ≤ 2V | |
| Protection circuit | DC(NPN,PNP) ：Polarity, overcurrent protection | |
| Indicator light | Green power indicator, red action indicator | |
| Ambient illuminance range | Incandescent: Spot intensity under 3,000Lx; Sunlight: Spot intensity: under 10,000Lx | |
| Temperature range | Operating: -25～+70℃ (no icing, condensation); Storage: -30～+70℃ (no icing, condensation) |
|
| Humidity range | Operation, storage: 35～85% (no condensation | |
| Sensing surface material | PC | |
1.Simple connection for easy installation
2.Multi-protection: polarity protection, over-current protection
3.Stable detection and strong resistance to light interference
4.Detecting distance is easy to set with one button
5.Press 5 times to quickly switch NO / NC of Action mode
